Cudy FS1026PS1 24 Port Gigabit PoE+ Unmanaged Switch

(0) 0 Reviews 0 Orders 0 Wish listed

Product Code: 126623

Key Features

Model: FS1026PS1
24 x 10/100M PoE+ ports
2 x Gigabit Uplink port
1 x 1.25Gbps SFP slot
300 Watts PoE power budget

৳13,250.00 ~~৳14,000.00~~

Quantity :

Quantity:

Total price :

(Tax : )

Overview
Reviews

Specification

Main Feature
Port	Max each port: 15.4W ( IEEE 802.3af ) Max each port：30W ( IEEE 802.3at ) PoE port output: DC48-55V
MAC Address Table	2K MAC address table
Environment	Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 85℃; Operating Humidity: Max 90%, non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters） Storage Height: Max to 10,000 feet (3,000 meters)
Hardware Features
LED	PWR – Power supply indicator(Red): Lighting: Powered Un-Light: No Power SW – DIP indicator(Green): OFF: Normal Vlan: Lighting Extend: Slow flash 1-27 – RJ-45 ACT indicator(Green): Lighting: Connecting Flashing: Data Transmit Un-Light: Disconnect
Power Supply	Power supply: 120W Power Pin: Power over spare pairs 1/2(+), 3/6 (-) PoE output-port: Max 30W
Dimensions (L x W x H)	32 x 21 x 4.6 cm
Weight	1900g
Manufacture Warranty
Warranty	01-Year

Description

Cudy FS1026PS1 24 Port Gigabit PoE+ Unmanaged Switch

The Cudy FS1026PS1 26-Port 10/100M PoE+ Switch with 1 FSP Slot makes it simple to manage your home or office network. It has 24 Ethernet PoE ports, 2 uplink ports, and 1 SFP slot. It's PoE RJ-45 connections support any 10/100Mbps Ethernet device, while the two non-PoE uplink ports support 10/100/1000Mbps Ethernet devices, and it complies with IEEE 802.3af/802.3at network standards. Used in a variety of applications The Cudy FS1026PS1 is compatible with IP Cameras for the home, workplace, or small company. It also works well with PCs, printers, and access points in your home or workplace, making it an excellent choice for small enterprises. It also includes a VLAN mode for further security, allowing the ports to be segregated from one another. It is extremely simple to use because of its basic plug-and-play interface. Its strong construction is built of high-quality metal. This extends the service life and improves heat dissipation, making it ideal for most settings. It also has a fanless design with venting holes to assist disperse heat while operating quietly. Watchdog ensures that your PoE devices run continuously. The PoE watchdog constantly monitors the status of distant hosts' connections. If a fault is identified on the remote PoE device, the PoE switch restarts it quickly to restore normal functioning. The Cudy FS1026PS1 24 Port Gigabit POE Unmanaged Switch comes with a 01-year warranty.
